Micro Drain Reel Inspection Scope - 65'

Price

$3,550.00

Specifications

Part #: ISMR65

Diameter

Pipe Application

Shipping Weight


Quantity:

  • Product Description
  • Specifications
  • Media Resources
  • Replacement Parts

Product Description

1¼" to 3 / 4" (32 - 75 to 100 mm)* lines up to 65' (20 m). Passes multiple 90° bends in most 1.5" (40 mm) drain lines.

microDrain™ video inspection system provides small size and maneuverability for small diameter and tight-turn radius inspections.

Lightweight and compact design is one-half the size of popular inspection systems, easily stowed in a truck and carried onto the jobsite.

Durable and reliable construction with hardened stainless steel camera head spring assembly for a long service life as well as long lasting high-intensity lights for exceptional viewing.

Ideal for inspections with tight turns such as flexpipe or even a single 90 degree elbow.

Lifetime Warranty held through Ridgid.  For more information and the register check out: https://www.ridgid.com/us/en/full-lifetime-warranty

Does not come with Monitor.  To purchase monitor check out: https://www.leaktools.com/ridgid-inspection-camera-monitor-and-scope.html

Specifications:

Camera Head

0.86" (22 mm)

Cable Length

65' (20 m)

Cable Diameter

0.33" (8,3 mm)

Line Capacity

1¼" to 3 / 4" (32 - 75 or 100 mm)

Weight

8.6 lbs. (3,9 kg) or 9.8 lbs. (4,4 kg)

Size

Length 13.25" (33.7 cm), Width 6.6" (16.8 cm), Height 14.2" (36.1 cm)

Resolution

656 x 492 NTSC

Ball Guide

2 included

Sonde

Standard with 65" (20m) microDrain, 512 Hz

Counter

Not available
